Eye swivel self-locking hook with bearing for rotation while loaded

SKB Series

  • Manufactured according to: EN 1677-3 / ASTM A 952
  • Swivels while loaded
  • 1,4 - 19 t Working Load Limit (WLL)
SKB Series
Specifications
Article Chain (mm) PCS / Pack Dimension (mm) Weight / PCS. (kg) / Approx WLL (t) / Max
        D E F F1 G H O (min) R
SKB6 6 14 35 13 35 30 16 20,5 28 160 0,8 1,4
SKB7-8 7-8 12 43,5 13 35 30 20 26 34 181 1,1 2,5
SKB10 10 6 56 16 41 37 24,5 30 45 218 2 4
SKB13 13 3 69 21 50 45 34,5 40 51,5 267 4 6,7
SKB16 16 1 80 25 65 55 35,5 50 60 325 8 10
SKB19-20 19-20 1 101 32 83 60 46 61 77 398 15,1 16
SKB22 22 1 110 35 90 74 51 67 84 448 20,9 19
